Whether your goal is to escape on gravel back roads, far from cars and crowds, toe the start line at your first gravel race, or simply get the most versatile bike on the road or dirt, no bike is better than the new Diverge.
It's quite simply the fastest, most capable - and just maybe the most fun - alloy bike we've ever made, delivering a ride that's quick and lively, but stable and confidence inspiring when the terrain gets rough.
With all-new gravel geometry and category leading tire clearance, the new Diverge represents everything we've learned over more than 40 years of riding road, gravel and dirt. The Diverge writes an entirely new chapter in the gravel bike category, so you can dream up entirely new rides.
It's the ultimate getaway vehicle.
The Diverge Elite E5 utilizes our premium E5 alloy frame and a full carbon FACT fork for a fast, confident and comfortable ride on road, in the dirt, and over thick gravel. Shimano's gravel inspired GRX 400 group shifts 2x10 gears smoothly on any terrain and Axis Elite alloy wheels with Road Sport 35mm tires provide an efficient ride on pavement with the versatility for hard pack dirt riding.
Shift Levers:
Shimano GRX RX400 hydraulic brake levers, 2x10 speed mechanical shifting
Crankset:
Shimano GRX RX600
Rear Derailleur:
Shimano GRX RX400, 10-speed
Cassette:
Shimano CS-HG50-10, 10-Speed 11-36t
Front Derailleur:
Shimano GRX RX400, braze-on
Chain:
KMC X10, 10-speed w/ reusable Missing Link™
Bottom Bracket:
Shimano 68mm threaded
Chainrings:
46/30T
Fork:
FACT carbon, full carbon steerer, 12x100 mm thru-axle, flat-mount
Saddle:
Body Geometry Bridge Saddle, steel rails
Stem:
Specialized, 3D-forged alloy, 4-bolt, 7-degree rise
Tape:
Specialized S-Wrap
SeatPost:
Alloy, 2-bolt Clamp, 12mm offset, 27.2mm, anti-corrosion hardware
Handlebars:
Specialized Shallow Drop, 6061, 70x125mm, 31.8mm clamp
Front Tire:
Specialized RoadSports, 700x35c
Inner Tubes:
Presta valve, 48mm
Rear Tire:
Specialized RoadSports, 700x35c
Front Wheel:
AXIS ELITE DISC
Rear Wheel:
AXIS ELITE DISC
Seat Binder:
Alloy, 30.8mm
Frame:
Specialized Diverge E5 Premium Aluminum, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
44 | 49 | 52 | 54 | 56 | 58 | 61 | |
---|---|---|---|---|---|---|---|
Crank Length | 165mm | 165mm | 170mm | 172.5mm | 172.5mm | 175mm | 175mm |
Stem Length | 60mm | 60mm | 70mm | 80mm | 90mm | 100mm | 100mm |
Handlebar Width | 360mm | 380mm | 400mm | 420mm | 420mm | 440mm | 440mm |
Seatpost Length | 350mm | 350mm | 350mm | 400mm | 400mm | 400mm | 400mm |
Saddle Width | 155mm | 155mm | 155mm | 143mm | 143mm | 143mm | 143mm |
Stack | 529mm | 545mm | 561mm | 578mm | 599mm | 618mm | 635mm |
Reach | 357mm | 365mm | 374mm | 383mm | 392mm | 401mm | 410mm |
Head Tube Length | 110mm | 125mm | 140mm | 155mm | 175mm | 195mm | 213mm |
Head Tube Angle | 69.5° | 70° | 70.5° | 71.25° | 71.75° | 71.75° | 71.75° |
BB Height | 270mm | 270mm | 270mm | 270mm | 270mm | 270mm | 270mm |
BB Drop | 80mm | 80mm | 80mm | 80mm | 80mm | 80mm | 80mm |
Trail | 72mm | 69mm | 66mm | 61mm | 57mm | 57mm | 57mm |
Fork Length, Full | 390mm | 390mm | 390mm | 390mm | 390mm | 390mm | 390mm |
Fork Rake/Offset | 55mm | 55mm | 55mm | 55mm | 55mm | 55mm | 55mm |
Front Center | 589mm | 598mm | 608mm | 615mm | 626mm | 641mm | 656mm |
Chainstay Length | 432mm | 432mm | 432mm | 432mm | 432mm | 432mm | 432mm |
Wheelbase | 1008mm | 1017mm | 1027mm | 1035mm | 1046mm | 1061mm | 1076mm |
Top Tube Length, Horizontal | 504mm | 521mm | 538mm | 554mm | 570mm | 584mm | 598mm |
Bike Standover Height | 680mm | 703mm | 723mm | 763mm | 789mm | 808mm | 834mm |
Seat Tube Length | 363mm | 390mm | 430mm | 470mm | 500mm | 530mm | 560mm |
Seat Tube Angle | 74.5° | 74° | 73.75° | 73.5° | 73.5° | 73.5° | 73.5 |
