Specialized 22 Vado 3.0 Red/Silver M
$3,249.99 Excl. tax
Add to cart
Specialized 22 Vado 3.0 Red/Silver M
Specialized
(0)

Specialized 22 Vado 3.0 Red/Silver M

$3,249.99 Excl. tax
In stock

Turbo Vado 3.0

Consider Vado your high-performance transportation bike, getting you where you’re going with an unmatched combination of speed, reliability, and confidence. Read more.

Product description

Specialized Turbo Vado 3.0



Consider Vado your high-performance transportation bike, getting you where you’re going with an unmatched combination of speed, reliability, and confidence. Whether you load it up with your stuff, or jump on and go, commute to work, or ride to the gym, Vado’s full power and huge range will get you from ‘point A’ to ‘point B’ ASAP.



The Specialized Vado has everything you need for e-powered transport. It brings a balanced nature to the way it handles and superior levels of comfort, plus a motor range of up to 90 miles.



This is a true class leader of its type.



TURBO: The heart of the Vado is its Turbo technology, an advanced and integrated electric bike system that delivers an unequaled combination of power, natural feel, anti-theft functions, training tips, a full-function bike computer, 93 miles / 150 km of range, and more.

POWERFUL: It’s you, just faster — it’s 4x You. The Turbo Full Power system senses the force you apply to the pedals and naturally quadruples it for an experience that makes getting up any hill or to any destination no sweat. Literally.

COMFORTABLE AND CONFIDENT: Body position and handling are optimized to deliver unsurpassed riding comfort, confidence, and control. Powerful hydraulic disc brakes reign in your speed, while larger tires provide maximum traction for turning and stopping.

SMOOTH: Stay comfortable in the saddle with an 80mm front suspension fork, and higher volume tires that smooths harsh bumps from points A to B.

SECURE: Vado has anti-theft lock built right into the bike. Prevent would-be bike thieves by disabling the motor with a press of a button so no one can turn on the motor without your phone connected to the Specialized app or your personalized pin. The Vado’s battery locks in the bike or can be easily taken with you. And if anyone tries to move your bike an alarm will sound. Beat it, thieves.



The speed limit at which the motor will stop supporting may vary significantly by region and is based on local requirements. It may also affect range: a higher speed limit may result in less range.



  • Turbo Full Power 2.0E motor and 530Wh battery offer an unparalleled riding experience, providing a smooth, seamless, and shockingly quiet amplification of your efforts, up to 28 mph. The integrated controller responds to your pedal inputs resulting in intuitive amplification of your efforts with an incredibly natural feel.



  • MasterMind and Specialized app - The MasterMind display reveals all relevant info about your ride and allows real-time tuning of support levels. MasterMind seamlessly integrates with the Specialized app for range optimization tools, advanced tuning, on-ride diagnostics, and more.



  • Proven Smooth Efficiency - We designed a custom testing mechanism to analyze bumps at even the smallest frequency to increase comfort and vision. That precision, paired with higher volume tires, and an 80 mm suspension fork, will flatten roads before your eyes.



  • Turbo System Lock - Use the Specialized app to disable your bike’s motor and activate the motion sensor alarm. Once locked, the motor cannot be enabled again except by the owner.



  • Fully Integrated Removable and Lockable Downtube Battery - Easy to charge, easy to secure.



  • Equipped with DRYTECH Fenders, LED front and rear lights, and 27kg capacity rear HD Rack. The rear rack is compatible with child bike seats, and the bike is also rated to pull a thru-axle trailer.



  • Long-Range - With a ride-anywhere range, go up to 68 miles (110 km) or 5 hours on a single charge (eco mode).





Technical Specifications



Accessories



Fenders:

Specialized DRYTECH fenders, 65mm width, aluminum fenderstay

Headlight:

Lezyne EBIKE MINI STVZO E65, 210 Lumen, 12V

Bell:

Simple bell

Taillight:

Spanninga Commuter Glow XE, 12V

Pedals:

Specialized Commuter w/ grip tape & reflectors

Kickstand:

Specialized kickstand, 40mm mount

Rack:

Specialized rack, MIK HD interface, built-in pannier mounts, 27kg max load

Bike Lock:

Turbo System Lock



Drivetrain



Chainrings:

Praxis, 48T, 104BCD

Crankset:

Custom alloy forged crankarms

Chaincase:

Custom chaincover

Chain:

KMC e9T, 9-speed w/ Missing Link™

Shift Levers:

Shimano Alivio, 9-speed w/ Optical Gear Display

Rear Derailleur:

Shimano Alivio, SGS, 9-speed

Cassette:

Shimano CS-HG400, 9-speed, 11-36t



Wheels & Tires



Rims:

650b disc, double-wall alloy, pinned, 32h

Spokes:

DT Swiss Industry

Rear Tire:

Pathfinder Sport Reflect, 650Bx2.3

Front Tire:

Pathfinder Sport Reflect, 650Bx2.3

Front Hub:

Specialized alloy front hub disc, sealed cardridge bearings, 6-bolt, 15x110mm thru-axle, 32h

Rear Hub:

Specialized alloy rear hub disc, sealed cardridge bearings, 6-bolt, 12x148mm thru-axle, 32h

Inner Tubes:

Standard 40mm SV 650Bx1.75-2.4



Frameset



Seat Binder:

Alloy, bolt-type, 34.9mm

Frame:

E5 Aluminum, bottom bracket motor mount, fully integrated &lockable downtube battery, internal cable routing, lock and front rack mount, sliding dropout



Cockpit



Saddle:

Rivo Sport, steel rails, 155mm

Grips:

Specialized Body Geometry Contour, lock-on

Stem:

Specialized Flowset, 3D-forged alloy, 20-degree rise, 31.8mm clamp

SeatPost:

Specialized, 6061 alloy, 2-bolt clamp, 0mm setback, 30.9mm

Handlebars:

Specialized, alloy, 15-degree backsweep, 46mm rise, 31.8mm



E-Bike



Charger:

Custom charger, 42V4A w/ Rosenberger plug, 100-240V

Wiring Harness:

Custom wire harness

UI/Remote:

MasterMind TCD, w/handlebar remote, built-in anti-theft feature, Bluetooth® connectivity, customizable display pages

Motor:

Specialized 2.0E, 50Nm torque, custom tuned motor, 250W nominal

Battery:

Specialized U2-530, alloy casing, state of charge display, 530Wh



Suspension



Fork:

SR Suntour MobieA32, 80mm travel, lockout, fender-mounts, integrated light mount



Brakes



Rear Brake:

Shimano BR-MT200, hydraulic disc, 160mm

Front Brake:

Shimano BR-MT200, hydraulic disc, 180mm



Weight



Weight:

24.9kg (54 lb, 14.3 oz)

Weight Size:

MD



* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.





Geometry


  S M L XL
Crank Length 170mm 170mm 170mm 170mm
Handlebar Width 680mm 680mm 680mm 680mm
Stem Length 60mm 60mm 75mm 75mm
Saddle Width 155mm 155mm 155mm 155mm
Seatpost Length 300mm 400mm 400mm 400mm
Stack 625mm 639mm 652mm 676mm
Reach 423mm 444mm 464mm 481mm
Headtube Length 135mm 150mm 165mm 190mm
Headtube Angle 68° 68° 68° 68°
BB Height 285mm 285mm 285mm 285mm
BB Drop 70mm 70mm 70mm 70mm
Trail 96mm 96mm 96mm 96mm
Fork Length (full) 480mm 480mm 480mm 480mm
Fork Rake/Offset 44mm 44mm 44mm 44mm
Front Center 699mm 724mm 750mm 777mm
Chainstay Length 470mm 470mm 470mm 470mm
Wheelbase 1160mm 1186mm 1212mm 1239mm
Toptube Length (horizontal) 585mm 615mm 645mm 675mm
Bike Standover Height 735mm 771mm 771mm 805mm
Seat Tube Length 400mm 450mm 460mm 500mm
Seat Tube Angle (Virtual) 75.5° 75° 74.5° 74°



Specifications

EAN Code
888818746583
SKU
95022-7803
